Comprehensive Insight · Real-Time Data

Delivering accurate and continuous patient monitoring.

12.1" HD Touch Screen

High-resolution 12.1-inch display with optional high-sensitivity capacitive touch screen, supporting smooth operation and intuitive gesture control.
Comprehensive Vital Signs Monitoring

Supports ECG, SpO₂, NIBP, RESP, TEMP and PR monitoring, with optional CO₂ and IBP modules for expanded clinical applications.
Pre-configured & Portable Design

Pre-configured design combines essential monitoring functions in a compact and portable platform for flexible deployment.
Dynamic EWS & Smart BP

Dynamic Early Warning Score (EWS) supports clinical assessment, while intelligent blood pressure measurement enables faster and more comfortable NIBP monitoring.
Wired Network & CMS Integration

Supports wired network connection to the Central Monitoring System (CMS), enabling centralized patient monitoring and data management.
Reliable & Eco-friendly Design

Built-in lithium battery, low power consumption and durable construction support reliable operation in demanding clinical environments.

Clear Display · Intelligent Alarms

High-definition visuals and smart alerts for clinical accuracy.

Fast & Accurate BP Measurement

The patented blood pressure algorithm provides short inflation time, fast measurement and reduced patient resistance.

Anti-Interference SpO₂ Algorithm

Advanced anti-interference SpO₂ technology provides accurate measurement even when the patient is moving.

Ultra-Low Perfusion Detection

Accurate low-perfusion monitoring and PI measurement help improve measurement stability and reliability.

Smart CO₂ Monitoring with Auto Zero

The CO₂ module supports a low sampling flow rate of 50 mL/min, with airway temperature and humidity measurement and compensation. Automatic zero setting helps eliminate measurement drift caused by changes in ambient conditions.

Long-Life Brushless Motor

The brushless motor provides a service life of more than 30,000 hours, supporting long-term reliable operation.

Durable TPU Protection & Shockproof Design

The anti-drop TPU case provides additional protection against impact and supports reliable use in clinical environments.

Clear Display · Intelligent Alarms

High-definition visuals and smart alerts for clinical accuracy.

Fast & Accurate BP Measurement

The patented blood pressure algorithm provides short inflation time, fast measurement and reduced patient resistance.

01/06
Anti-Interference SpO₂ Algorithm

Advanced anti-interference SpO₂ technology provides accurate measurement even when the patient is moving.

02/06
Ultra-Low Perfusion Detection

Accurate low-perfusion monitoring and PI measurement help improve measurement stability and reliability.

03/06
Smart CO₂ Monitoring with Auto Zero

The CO₂ module supports a low sampling flow rate of 50 mL/min, with airway temperature and humidity measurement and compensation. Automatic zero setting helps eliminate measurement drift caused by changes in ambient conditions.

04/06
Long-Life Brushless Motor

The brushless motor provides a service life of more than 30,000 hours, supporting long-term reliable operation.

05/06
Durable TPU Protection & Shockproof Design

The anti-drop TPU case provides additional protection against impact and supports reliable use in clinical environments.

06/06

Smart Connectivity · Smooth Workflow

Simplifying clinical processes through seamless integration.

Intuitive Menu Design

A single-interface, three-stage menu design enables 95% of operations to be completed within two steps, simplifying routine clinical procedures.
Customizable Parameter Layout

Users can customize parameter arrangements and select large numeric displays according to different clinical requirements.
Multiple Display Modes

Supports multiple display interfaces, including standard view, big numeric display and full-screen 7-lead ECG view, providing flexible visualization for different monitoring scenarios.
Convenient Hotkey Operation

Multiple hotkey editing functions provide quick access to frequently used operations and help improve workflow efficiency.
Integrated Clinical Tools

Integrated EWS and hemodynamic functions provide additional clinical information for patient assessment and monitoring.

Connected Care · Future Monitoring

Advancing data-driven insights for next-generation patient care.

Parameter Type

Function Description

Display

12.1-inch HD display; 1280 × 800 or 1920 × 1080 pixels; optional capacitive touchscreen
ECG Leads

3-lead / 5-lead ECG; ST analysis, arrhythmia analysis and pacemaker detection
SpO₂

Range: 0–100%; Accuracy: ±2% (70–100%); PI: 0.05–10%
NIBP

Adult / Pediatric / Neonate modes; intelligent measurement; systolic, diastolic, mean and PR
Respiration

RR range: 0–120 rpm; multiple lead selections
Temperature

2 channels; range: 0–50°C
PR

Range: 30–250 bpm; Accuracy: ±2% or ±2 bpm
IBP

Optional; 2 channels; range: –50 to 400 mmHg
CO₂

Optional mainstream & sidestream; sampling flow as low as 50 mL/min
