Comprehensive Insight · Real-Time Data

Delivering accurate and continuous patient monitoring.

Basic Vital Signs Monitoring

Standard parameters: ECG (3/5-lead), SpO₂, NIBP, RESP, TEMP, PR. Optional: CO₂, IBP.
Flexible Respiration Lead Options

Supports RA-LA, RA-LL, LA-RL, LL-RL lead selections for respiratory monitoring.
Compact & Portable Design

Integrated lightweight structure with built-in lithium battery for bedside or transport use.
Multi-Display Interface Modes

Normal view, big numerics, and full-screen 7-lead ECG display options.

Clear Display · Intelligent Alarms

High-definition visuals and smart alerts for clinical accuracy.

Fast & Comfortable BP Measurement

Patented oscillometric algorithm enables short inflation time, rapid reading, and reduced patient resistance.

Accurate SpO₂ Even During Motion

Anti-interference SpO₂ algorithm ensures reliable readings under patient movement or weak perfusion (PI ≥ 0.075%).

Long-Life Gas Sampling System (Optional)

Ultra-long-life gas sampling tube (>10 days); brushless motor rated for >30,000 hours.

Auto Zero Calibration

Automatically adjusts zero point based on ambient temperature and humidity to eliminate drift.

Durable Protection

Drop-resistant TPU case enhances reliability in mobile or rugged environments.

Clear Display · Intelligent Alarms

High-definition visuals and smart alerts for clinical accuracy.

Fast & Comfortable BP Measurement

Patented oscillometric algorithm enables short inflation time, rapid reading, and reduced patient resistance.

01/05
Accurate SpO₂ Even During Motion

Anti-interference SpO₂ algorithm ensures reliable readings under patient movement or weak perfusion (PI ≥ 0.075%).

02/05
Long-Life Gas Sampling System (Optional)

Ultra-long-life gas sampling tube (>10 days); brushless motor rated for >30,000 hours.

03/05
Auto Zero Calibration

Automatically adjusts zero point based on ambient temperature and humidity to eliminate drift.

04/05
Durable Protection

Drop-resistant TPU case enhances reliability in mobile or rugged environments.

05/05

Smart Connectivity · Smooth Workflow

Simplifying clinical processes through seamless integration.

Clinically Optimized Layout

Customizable parameter arrangement and large-font numeric display tailored to real-world clinical workflows.
Efficient Two-Step Operation

Single-interface + three-stage menu design ensures 95% of operations are completed within 2 steps.
Quick Access via Hotkeys

Various hotkey editing functions enable faster navigation and operation.
Intuitive Touchscreen (Optional)

High-sensitivity capacitive touchscreen supports smooth, multi-touch operation (optional configuration).

Connected Care · Future Monitoring

Advancing data-driven insights for next-generation patient care.

Parameter Type

Function Description

Display

12.1-inch LCD high-brightness screen, 1024×768 resolution
Weight

2.4 kg
Dimensions

304 mm × 151 mm × 275 mm
ECG Leads

3-lead (I, II, III) / 5-lead (I, II, III, aVR, aVL, aVF, V)
SpO₂ Perfusion Index (PI)

Detectable down to 0.075%
NIBP Range (Adult)

Systolic 30–260 mmHg, Diastolic 10–220 mmHg, Mean 20–230 mmHg
CO₂ Sampling Flow

Minimum 50 ml/min (optional sidestream module)
Battery

Built-in rechargeable lithium battery
